Refrigerated Vehicle Bodies

 Refrigerated Vehicle Bodies

Dsp manufacturers insulated vehicle bodies for transporting refrigerated cargo in the state of Qatar Since 2010. The use of Poly Urethane Sandwich Panels used for this purpose has lots of advantages like providing superior insulation property, lightweight construction, lower fuel consumption and increased useful life of the insulated body etc.

gallery/q7

Technical Specification

Specifiactions

 Refrigerated cargo Body

Sub Frame Base

Heavy Duty Steel

Wall & Roof Panel Thickness

100mm or 150mm

Flooring

GRP/ Aluminum Chequer Plate / T Section

Rear Doors

Double Leaf & Triple Leaf

Side Door Option

Single Leaf

Door Locking system

Container type locking gear

Door Hinges

Heavy Duty Stainless Steel

Door Curtains

Polar Strip Curtains ( Standard )

Ceiling Light

L.E.D

Frame

Extruded Aluminium Profiles

Side Under Run Protection

Standard

Rear Bumper

Standard Step Bumper / Foldable Step

Cooling Unit

As per Requirement

Standard Insulated Body Sizes( Length X Width X Height X )

Truck Size

External Dimensions in mm

Internal Dimensions in mm

3 Ton

4300x2100x2100

4100x1900x1900

4 Ton

5000x2100x2100

4800x1900x1900

5.8 Ton

5500x2200x2100

5300x2000xI900

7 Ton

6000x2300x2300

5800x2100x2I00

10 Ton

7000x2500x2500

6800x2300x2300
